3D Printing 101

It is basically a very precise hot glue gun

3D printer plastic comes as a long strand called filament, wound on a spool like really thick fishing line.

The printer pulls the filament into a hot end, melts it at around 220°C, and squeezes it out of a tiny nozzle less than half a millimeter wide.

• the spool
  filament goes in…
• →
• the hot end
  220°C!
• →
• …layers come out

spool → melty bit → toy. that is honestly most of it

Hundreds of pancake-thin layers

The nozzle draws one slice of the toy at a time, like a pen that never lifts. Each layer is about 0.2 mm tall, thinner than two sheets of paper.

When one layer is done, the printer moves up a hair and draws the next one on top. A small toy is a few hundred layers and takes a few hours. The biggest prints take most of a day.

• the slicer
  chops the model into layers
• →
• the nozzle path
  one slice at a time
• →
• layer on layer
  about 0.2 mm each

A computer program called a slicer does the math: it takes a 3D model and chops it into all those layers, then writes the path the nozzle will follow. That is the boring-sounding part that is secretly the most important.

The magic trick: print-in-place

Here is the part that surprises grown-ups. The printer can leave tiny gaps on purpose.

The dragons we print under license (Cinderwing3D designs them) have body segments that wrap around each other with a small gap between them. So the printer builds all the segments at once, already linked, never touching.

When the print finishes, the whole dragon bends straight off the plate. No screws, no glue, no assembly. That is called print-in-place, and it is why the flexi toys wiggle the moment you pick them up.

• tiny gaps, printed empty
• →
• so it bends right away!

print-in-place: born already wiggling

Why it is a big deal for toys

• No molds. A factory toy needs a metal mold that costs thousands of dollars, so factories only make things millions of people will buy. My printer needs a file. I can invent a toy on Tuesday and have it on my market table on Saturday.
• Made near you, in small batches. My toys are printed in our house in Texas, not shipped across an ocean to sit in a warehouse. Less waste, and no unsold mountains of plastic.
• One-of-a-kind is free. Changing a color or a design costs nothing. That is why the Imaginator can turn your idea into a real printable model, and why the Oops Shelf exists: even the mistakes are originals.
• Kids can be manufacturers. This is the part I care about. The same machine a company uses for prototypes fits on a desk and obeys an eight-year-old. That was not true when Dad was a kid.

Mostly the toys are made of PLA, a plastic made largely from corn starch, which prints beautifully and comes in wild colors, glow, silk and sparkle. The see-through toys are PETG, the tougher cousin of water-bottle plastic.

Every filament we use is from Bambu Lab, and the manufacturer safety documents for each one are published on our safety page.

Quick honesty note: 3D printed things are never food-safe, whatever plastic they use, because the layer grooves cannot be cleaned like a smooth cup. Toys are for hands, not mouths.
